Atomizing Disinfection Robot
Features:
* Support the use of disinfectants such as hydrogen peroxide, sodium hypochlorite, and peracetic acid.
* The large-capacity 16L disinfectant tank can continuously disinfect for more than 5 ~ 6 hours, and the disinfection
coverage is up to 4000 ~ 5000 m2.
* Support APP control, no-touch automated disinfection greatly improve the safety of use in the disinfection process.
* Two disinfection modes: timed disinfection and immediate disinfection.
* With autonomous navigation function, lidar obstacle avoidance, can fully cover the required area.
* Support automatic return to charge, human assistance isn't required.
* When the disinfectant is below the warning position, it will return to the waiting area and turn off the spray
device automatically.
Applications:
It can be widely used in hospitals, airports, office buildings, shopping malls, schools, factories and other public places.
Model | BKS-Y-800 | |
External Size(mm) | φ500*1335 | |
Atomization Efficiency | 2L~3L/H(adjustable) | |
Disinfectant Capacity | 16L | |
Spray Diameter | 5-6m | |
Disinfection Medium | Hypochlorous acid,Chlorine dioxide,Hydrogen peroxide,Peroxyacetic acid, etc. | |
Spray Method | Four-direction spray, large opening spray(optional) | |
Moving Way | Autonomous path planning and automatic navigation | |
Moving Speed | 0~0.6m/s | |
Power Supply | AC220±10%V 50Hz | |
Consumption | 150W | |
Drive Method | Differential drive | |
Ability to Cross Obstacles | ±10mm | |
Gradeability | ≤8° | |
Driving Channel Width | ≥700mm | |
Noise | ≤50dB | |
Operating Time | 5~6h | |
Battery | Lithium battery 28AH 24V | |
Charging Time | 3~4h | |
Safety System | Lidar obstacle avoidance, power-off protection of disinfectant shortage | |
Package Size | Main Body | 430*430*660mm |
Chassis | 650*650*770mm | |
Gross Weight | Main Body | 10kg |
Chassis | 62kg | |
Factory Views:
Founded in 1999, BIOBASE Group having over 2000 employees (till August, 2018), BIOBASE Group is a new high-tech enterprise focusing on development, production and management of scientific equipment, In Vitro Diagnosis (IVD) instrument and reagent.
